- E-bike
-
- Battery
- 840Wh battery
-
- UI/Remote
- Mastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My
-
- Motor
- Specialized 3.1 Motor, 105Nm torque, 810W power
-
- Charger
- Specialized 4amp charger
- Frameset
-
- Seat Binder
- Alloy, 38.6mm
-
- Frame
- Levo 4 alloy frame, 150mm travel, adjustable chainstay, adjustable head tube angle, adjustable bottom bracket, internal SWAT storage 148mm spacing, 29" front wheel/27.5" rear wheel
- Suspension
-
- Fork
- FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset
-
- Rear Shock
- Fox FLOAT X Genie, Performance series, 210x55, Low speed rebound adjust, climb switch
- Brakes
-
- Front Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor
-
- Rear Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor
- Drivetrain
-
- Cassette
- SRAM 12-speed,10-52t
-
- Chainrings
- SRAM 34t T-Type chainring, 104 BCD, steel
-
- Chain
- SRAM 70 Transmission 12-Speed Flattop Chain
-
- Rear Derailleur
- SRAM Eagle 90 T-Type
-
- Shift Levers
- SRAM Eagle 90T, single click, with MMX
-
- Crankset
- SRAM S1000 Alloy crank, ISIS interface, 155mm length
- Wheels & tires
-
- Rear Tire
- Butcher GRID Gravity Radial T9 TLR Enduro Tire 27.5x2.4
-
- Front Tire
- Butcher GRID Gravity Radial T9 TLR Enduro Tire 29x2.4
-
- Spokes
- DT Swiss Elemental
-
- Front Hub
- Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h
-
- Rear Hub
- Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12x148mm thru-axle, 32h, HG Steel Fhb
-
- Rims
- Specialized, hookless alloy, 30mm inner width, tubeless ready
-
- Inner Tubes
- Standard, Presta Valve
- Cockpit
-
- Stem
- Alloy Trail Stem, 35mm bar bore
-
- Handlebars
- Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise
-
- Saddle
- Bridge Comp, Hollow Cr-mo rails 155/143
-
- Grips
- Specialized Trail Grips
-
- Seatpost
- Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S5: 170, S4: 200mm, S5-S6: 230mm
- Accessories
-
- SWAT
- SWAT Internal downtube storage
- Product details
-
- Product ID
- 263405
-
- Compliance Certification
-
As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS.
For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fd... class="product-specification"> - Weight
-
- Weight
- 26.37 kg (58 lb, 2.2 oz)
-
- Weight Size
- S4
